Owner's Manual

VIANO Type 01

Designed to be effortless.

Set-up takes less than one minute.

Before You Start

Ensure the diffuser is fully charged.

Make sure the diffuser is powered off.

Place it on a flat surface.

Handle it upright if it already contains oil.

Set-Up

Open the diffuser

Unscrew the bottom metal cover of the diffuser.

Important

If the diffuser already contains oil, do not tilt it or turn it upside down — this prevents spills.

Remove the bottle (if replacing)

Turn the existing bottle anticlockwise to remove it. Keep the diffuser upright at all times.

Prepare your fragrance bottle

Remove the bottle cap. Insert the cotton core fully into the bottle, seated properly for clean diffusion.

Note

If any fragrance oil comes into contact with your skin, simply rinse it off.

Install the bottle

Attach the bottle to the diffuser and turn clockwise until securely fastened. Do not over-tighten.

Close the diffuser

Screw the metal base back on gently until flush.

Power On & Off

Power on

Press and hold the power button for three seconds. The indicator lights illuminate briefly, and the diffuser starts using your last saved settings.

Power off

Press and hold the power button again for three seconds. The lights turn off, confirming shutdown.

Smart Auto Start & Stop

Hands-free, by design

The Type 01 is equipped with motion sensing. When your car is moving or running, diffusion is active. If no movement is detected for 200 seconds, the diffuser enters Standby Mode. When driving resumes, diffusion restarts automatically using your last settings.

No need to touch anything.

Scent Gears & Diffusion

Control how often fragrance is released

1 Light	Every 20 seconds — stronger presence
2 Lights	Every 90 seconds — balanced
3 Lights	Every 180 seconds — subtle, refined

Normal Mode (blue light)

You manually select your preferred gear. Ideal for consistent control.

Auto Mode (purple light)

The diffuser automatically switches to the next gear after six sprays. Ideal for long drives and conserving fragrance.

Button Controls — Quick Reference

Press once	View current gear
Press again	Switch to the next gear
Double press	Switch between Normal and Auto Mode

Placement

Where to place it

Place the diffuser securely in your rear cup holder for optimal airflow and stability. Alternatively, rest it on any flat surface in the car using the non-slip mat provided.

Care

◆Protect your interior

In the event of a spill on plastics, leather or the console, wipe it up immediately to prevent discolouration.

◆Temperature control

To preserve fragrance quality and battery life, avoid leaving the diffuser in direct sunlight or extreme heat for prolonged periods.

◆Safety first

Keep the diffuser and fragrance bottles out of reach of children and pets.

◆Maintenance

Wipe the exterior with a dry microfibre cloth. Use VIANO fragrance refills only.

That's it.

Your VIANO Type 01 is ready for every drive.
